This seminar is closed.

MIDAS GEOTECHNICAL WEBINAR

Tunneling Short Course in Midas GTS NX

- India: 03:30 PM to 04:30 PM (IST)
- Africa: 10:00 AM to 11:00 AM (GMT)
- Middle East: 02:00 PM to 03:00 PM (GST)

  • 9-Sessions Training Course (April 20 ~ May 8 )

OVERVIEW

MIDAS launches a Short Course for the Geotechnical Engineers focused on Finite Element Methodologies in Tunnel Engineering. This course will provide e-learning opportunity by our MIDAS expert engineer. This course will help you enhance Modelling and Analysis aptitude using the geotechnical software tool midas GTS NX

AGENDA

  • Session 1

    (April 20, 2020)

    Getting Started with GTS NX
    Get yourself acquainted  with various Modelling and Analysis features of GTS NX



  • Session 2

    (April 22, 2020)

    Twin Metro Tunnel in Layered Soil (2D)

    Urban Subway scenario demands Excavation of Twin Tunnels & as they run  parallel along the length, the model can be 2D with Plain Strain Condition which is dealt in this session.

  • Session 3                (April 24, 2020)

    Construction Stage Analysis of Simple Circular Tunnel with Shotcrete Lining (3D)

    Discussion on Simple Circular Tunnel with Shotcrete in 3D, considering Analysis across the Stages of Construction focusing on the stress dispersion during these stages.

  • Session 4              (April 27, 2020)

    Quick Modelling and Analysis of Horse Shoe Tunnel with Lining and Rock-bolts using Tunnel Wizard (3D)

    Let’s explore quick modelling techniques with midas GTS NX Tunnel Wizard feature that requires negligible effort to modell a Tunnel in 3D along with  Boundary Conditions

  • Session 5              (April 29, 2020)

    D Shaped Railway/Roadway Tunnel in Hilly Terrain (3D)

    Predicting the Slope/Terrain & Tunnel behavior with Staged Excavation in Railway & Roadway Tunnels for Hilly Terrain, where prediction of displacement/stresses are difficult and conservative

  • Session 6

    (May 01, 2020)

    Double Lined Tunnel Modelling (3D)

    Tunnel behavior with linings in stages of excavation can be predicted with ease using GTS NX features. Especially in  NATM construction where Primary  & Secondary lining resists Short & Long term ground loads respectively.

  • Session 7

    (May 04, 2020)

    Construction Stage Analysis of Tunnel with Cross Passage using Stage Wizard (3D)

    2D Analysis & Design of Tunnels cannot appropriately access the behavior of Cross & Main Tunnel Intersection, which is more vulnerable. This session covers the necessary 3D Modelling & Analysis approach in this regard.

  • Session 8

    (May 06, 2020)

    Deep Excavation for Metro Station (3D)

    Discussion on the impact of Deep excavation in Urban Areas  with restricted  choice of lateral support system ( D-walls, Walers, Struts and Anchors) due to presence of adjacent Buildings, Bridges and Tunnels, with special attention on Metro Station

  • Session 9

    (May 08, 2020)

    Lowering of TBM Shaft into the Tunnel -Modeling and Analysis (3D)

    One of the purpose of Shaft is for the TBM to enter the  Launch Chamber. Discussion on how an appropriate 3D  FEM approach can be adopted to examine the most vulnerable, intersection behavior of Shaft-Launch Chamber & Tunnel.

Take-Away

After successful completion, you will

1) Have better command on the Geotechnical Software midas GTS NX

2) Quick modelling techniques using midas GTS NX Tunnel Wizard

3) Implication and methodology in implementing Construction Stage Analysis at different Stages in Tunnel



As a participant in this nine-day course, you get

On Completion of Session 1 till 6Certificate

Course Completion Certificate

On completion of All Session

midas_tshirt

Midas T-Shirt (India Region)



In order you get a first hand experience, we have also enabled



Speakers

  • harsha

    Geotechnical Engineer, MIDAS IT

    Tunneling Short Course in midas GTS NX

    Tadavarthi Sree Harsha
    Tadavarthi Sree Harsha

    His main role is to work closely with geotechnical engineers around the world to ensure they are satisfies with midas geotechnical software products ( GTS NX, Soil Works) and cater to areas if improvement. He also manages multiple training programs to show the shortest path to completion of wide variety of Geotechnical Projects.
